9QS-3600T

Meidi 9QS-3600T Self-propelled Green Feed Harvester is a brand-newly designed high-end intelligent large-scale silage harvester, with a new main machine layout in which there is a large internal space for easier maintenance and caring; a header with a cutting width of 3.6m and a 480 HP engine are equipped for easy harvest of high-yield silage corn; the corn slicing and crushing effect can be on a par with imported machine by the new-type chopping hobbing cutter and grain crusher with a larger diameter; the spacious cab equipped with A/C make the working environment more comfortable; multi-functional armrest box and control handle can control the harvest working easily. 2024 Meidi Green Feed Harvester is trustworthy with advanced and reliable technology and excellent harvest quality.


Product Details

Product Technical Parameters
1Model Name/9QS-3600T Self-propelled Green Forage Harvester
2form/Self-propelled
3Working state dimensions (length x width x height)mm8010X3710X5870
4Matching engine rated powerkW353
5Matching engine rated speedr/min1900
6Cutting widthmm3520
7Crop collecting header type/Straight cutting table
8Header cutter type/Disc cutter
9Feeding mechanism type/Feeding roller
10Number of feeding mechanismsindivual4
11Straw chopping mechanism type/Drum type
12Grain crushing mechanism type/Roller type
13Speed Shift/Manual speed shift
14Drive mode/Hydraulic drive
15Brake type/Disc
16Steering wheel trackmm2110
17Guide wheel tire specifications/500/60-22.5
18Driving wheel trackmm2400
19Driving wheel tire specifications/750/65R26
20Wheelbasemm2710
21Designed cutting lengthmm1st gear: short 6; long 8
2nd gear: short 11; long 14
3rd gear: short 18; long 22
